Effluent Treatment Plants
We Design, Manufacture, Supply, Erection and Commissioning Effluent Treatment Plant (ETP) on a Turnkey basis for various types and natures of wastewaters, effluents that combine advanced physio-chemical treatment processes with a tertiary polishing system for the removal of organic, inorganic, oil, and grease, heavy metals & suspended solids.
Our methodology – We analyze the effluent samples for different effluent parameters as per nature and compositions, carry out the treatability studies by using different methods checking techno-commercial Feasibility, and then design treatment schemes, processes accordingly to suit the purpose and need.
Our ETP systems are very compact, tailor-made designs, portable required very less footprint to accommodate, energy-efficient. The up-gradation, modification in the existing ETP system is possible to achieve desired limiting standard laid down by the Pollution Control Board (PCB).
The principle of operation of ETP is Physico-Chemical treatment followed by Polishing Treatments like –Sand Filtration, Activated Charcoal treatment (Adsorption), Ozonisation (Chemical Oxidation), Ultra Filtration (UF), Reverse Osmosis (RO), and evaporation (If required).
ETP Containerized Type
Capacity: 25 – 150 KLD, As per client Requirement
Technology: Physical / Chemical / Biological / filtration
Features:
- Semi-automatic Operation.
- Required less space as compared to conventional design.
- Very Compact and Great aesthetic.
- Reduced Installation and commissioning time on site.
- Plug and play operation.
- Easy Dismantling and transportation.
- Made to order product.
- Civil Work – Collection Tank and Container Foundation.
Typical Industries: Chemical, Pharmaceuticals, Automobiles, etc.
ETP – Continuous Type
Capacity: 15 to 1000 KLD, As per client Requirement
Technology: Physical / Chemical / Filtration
Features:
- Semi-automatic Operation.
- MS process tanks with internal FRP Coating
- Automatic chemical dosing with online pH monitoring.
- Advanced Filtration systems like UF, RO for Zero liquid discharge.
- Advanced sludge handling system.
- Compact design, required low foot print
- Better treated effluent quality as compare to conventional system.
- Corrosion free UPVC piping & FRP / Epoxy Lined MS tanks.
- Process Tanks – MS Fabricated / Civil (RCC)
Typical Industries: Automobile, Metal pre-treatment, Pharmaceuticals, Chemical, etc.
